Disrupting the Traditional Injection Molding Process

The traditional approach to injection molding has been tried and true for designers for many decades. But as manufacturing technology has advanced, the need for simulation to be applied earlier and throughout the design process has grown. Even though the process for creating injection-molded parts has proven successful over the years, common defects such as sink marks, air traps, and weld lines can fly under the radar with physical testing. By exploring the capabilities of digital design and simulation, teams have the ability to make noticeable time and cost savings. A significant reduction in prototypes is the result of simulation-driven design, so molding projects can be completed faster and with less defects.

A standard approach to injection molding usually consists of designers creating an initial blueprint for a part or mold, putting it into the testing and validation phase, and having to circle back to phase one if an error is caught before manufacturers put it into full production. Failing to notice those key issues in a design ends up impacting its manufacturability and becomes expensive.

These iteration loops end up affecting the entire production line, and results in a big loss of productivity. Injection molding is a highly sophisticated manufacturing process, which makes discovering the source of defects extremely difficult when relying on testing alone. By leveraging a simulation-driven design approach, design engineers can identify potential issues early and modify their part or manufacturing process parameters to yield a better part the first time. Taking a look at some of the most common challenges of injection molding, we’re able to see how breaking out of old habits can bring a fresh perspective to an established manufacturing process.

Addressing known disadvantages

When laying the groundwork for injection-molded parts, project teams have to consider the relationship between numerous variables at each step of the injection molding process. This includes factors such as the tooling involved, part materials, and selected mold and part configurations.

Because part designers and mold makers tend to work sequentially, this is where iteration loops in the production workflow begin to waste time and resources. The “trial-and-error” approach requires waiting until a prototype has been created to test it and validate it, and even that can take several attempts to find the right design. This is where Altair Inspire Mold™ can help everyone in both engineering and manufacturing to work off the same page. Applying integrated simulation across the entire design workflow allows teams to understand how all of those process variables will end up affecting a component’s design, meaning earlier optimization and less scrap work. As a single, integrated platform, Inspire Mold is accessible to all users with different software experience levels. Additionally, designers can achieve rapid solution times online without needing to invest in expensive hardware.

Read the full article here.
